Order Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removal of stale or exhaust air from rooms through the roof, Motor protection class IP 54 in Valencia at a great price

Buy Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removing stale or exhaust air from rooms through the roof, motor protection class IP 54 at Factory Prices
Buy Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removing stale or exhaust air from rooms through the roof, motor protection class IP 54 at Factory Prices
Buy Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removing stale or exhaust air from rooms through the roof, motor protection class IP 54 at Factory Prices
Buy Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removing stale or exhaust air from rooms through the roof, motor protection class IP 54 at Factory Prices
Order Roof fan Aerostar SRP 56/35-4D, with increased performance, for large areas, removal of stale or exhaust air from rooms through the roof, Motor protection class IP 54 in Valencia at a great price
0 reviews • Write a review
from
478.47 €
Ex Tax: 395.43 €
  • Availability: 99
  • Brand: Aerostar
  • Model: 952732165
  • Weight: 1.00kg
  • UPC: 952732165
  • JAN: kr-24840
Add to cart
Buy Now Question?
Add to favorites Compare

Before placing an order, contact DOMIS.PRO to confirm delivery availability and arrangements for your chosen product, including the destination, delivery method, cost and timing.

For questions about returns or exchanges, contact DOMIS.PRO. Provide your order number and the product name so we can discuss your situation and the next steps.

Before ordering, check the specifications, dimensions and compatibility of the chosen product with your equipment or project.

If the product page does not provide enough information, ask DOMIS.PRO and include the model or product code. Confirm the supplied components and any specifications that matter to you before placing an order.

Accessories for exhaust ventilation Aerostar TR 40, connecting element between roof fans Aerostar SRV/ARV series and air duct network, reliable connection and protection against water ingress into the room, made of high-strength galvanized steel
Quick view
Accessories for exhaust ventilation Aerostar TR 40, connecting element between roof fans Aerostar SRV/ARV series and air duct network, reliable connection and protection against water ingress into the room, made of high-strength galvanized steel
137.91 €
Ex Tax:113.97 €
Add to cart Add to favorites Compare
Adapter FMK 100
Quick view
Adapter FMK 100
11.73 €
Ex Tax:9.69 €
Add to cart Add to favorites Compare
Adapter FMK 100 C
Quick view
Adapter FMK 100 C
11.64 €
Ex Tax:9.62 €
Add to cart Add to favorites Compare
Adapter FMK 125
Quick view
Adapter FMK 125
13.20 €
Ex Tax:10.91 €
Add to cart Add to favorites Compare
Adapter FMK 150
Quick view
Adapter FMK 150
16.62 €
Ex Tax:13.73 €
Add to cart Add to favorites Compare
Adapter FMK 150 C
Quick view
Adapter FMK 150 C
15.06 €
Ex Tax:12.44 €
Add to cart Add to favorites Compare
Adapter FMK 200
Quick view
Adapter FMK 200
19.87 €
Ex Tax:16.42 €
Add to cart Add to favorites Compare
Adapter FMK 200 C
Quick view
Adapter FMK 200 C
17.76 €
Ex Tax:14.67 €
Add to cart Add to favorites Compare
Tags: ventilation , aerostar

Basic information Aerostar SRP 56/35-4D roof fan

Roof fan Aerostar SRP 56/35-4Dis a largely improved model that shows increased performance and is suitable for rooms with a significant extended area. This unit is used to remove stale or exhaust air from premises through the roof. Fastening is carried out on the upper part of the building, in interaction with supply and exhaust air duct systems, while providing the most comfortable conditions. The fan can be used in industrial or public premises, for example, in workshops, warehouses, gyms, office premises, supermarkets, exhibition or sales halls, covered parking lots, etc. The improved design will allow you to interact not only with dry, but also with average humidity air.

You will ensure uninterrupted operation, with low noise levels and economical energy consumption. For detailed information about the presented model, you should contact the managers of the Domis online store. Only our professional team is always ready to assist in choosing high-quality ventilation equipment.

Dimensions

< /tr>
DesignationDimensions, mmWeight,

kg
ABBCDG
SRP 56-355-4D4004105397804040033
SRP 56-400-4D560 4305837804056039
SRP 63-450-4D630475 612.58704063046
SRP 63-500-4D630530741.5920 4063057

Design feature

The fan housing is made of galvanized steel of increased strength. This material is not subject to corrosive formations and oxidation, significantly extending the nominal service life. The impeller with backward curved blades is also made of galvanized steel, which will not only lighten the nominal weight of the fan, but also achieve improved aerodynamic performance in the formation of a powerful air flow. The fan diffuser is made of aluminum.

Roof fan Aerostar series SRPis equipped with a high-quality asynchronous motor with an external rotor. To prevent the possibility of overload or overheating, special thermal contacts are installed on the fan, which ensure automatic shutdown of the entire system, with the possibility of further restart. The fan meets high European quality standards and comes with a guarantee from the manufacturer.

Motor protection class IP 54.

Speed adjustment

Control over the accuracy of the fan operation is ensured through interaction with an RTT step transformer regulator, as well as through a frequency converter.

Installation

The fan is mounted on the roof, fixed in a horizontal position. The connection is made to air duct pipes of a certain diameter. This process is quite simplified and will not take much time.

In order to buy an Aerostar SRP 56/35-4D roof fan, you should contact our managers Domis companies, who are always ready to provide professional advice on choosing the best ventilation equipment at an affordable price. Delivery is carried out to any point in Kyiv and Ukraine, using a carrier or courier service convenient for you.

Call and get a discount!

Characteristic
Rotation speed, min-1 1350
Weight, kg 33
The phase 3 phases - 380 V
Noise level, dB 45-59 (Clearly audible)
Power consumption, W 250
The maximum temperature of the transported air, 0C 80
Protection, class IP54
Voltage, V 380
Current, A 0.82
Pipe size, mm 400
Current frequency, Hz 50
MODEL NAME SRP
