DOMIS catalogue
Browse the DOMIS catalogue and compare materials, formats and options for your project.
Ask a question about this product
- Availability: 98
- Brand: Domis
- Model: 952811770
- Weight: 3.00kg
- UPC: TELECOMMANDE
domis.pro offers several models of remote controls compatible with radio control. All of them indicate a certain number of channels. Here is the meaning of this important remark that you need to know:
- 1 channel: this means that the command transmitted from the remote control will be transmitted to one motor or a group of 20 motors. In the latter case, the engines will be synchronized with each other.
- 5 channels: this means that the command transmitted from the remote control will be transmitted to 5 motors individually or up to 5 groups of 20 motors each. The engines within the same group will be synchronized with each other.
- 15 channels: this means that the command transmitted from the remote control will be transmitted to 15 motors individually or up to 15 groups of 20 motors each. Engines within the same group will be synchronized between
Features of remotes
These remote controls for blinds and awnings are compatible exclusively with AvosDim radio drives. Powerful, with a range of 200 m outdoors and 35 m indoors. The frequency is 433.90 MHz (100 kHz). The operating temperature range is very wide: from -10°C to +50°C. And for your convenience, they are all equipped with batteries and a wall mount.
| Link | Number of channels | LED screen | Programming | Sizes | batteries |
| 005207 | 1 | No | No | 80*80mm | 1 3V CR2430 battery |
| 005202 | fifteen | Aha | No | 143*40*20mm | 2 1.5V batteries |
| 005203 | 1 | No | No | 120*40*10mm | 1 3V CR2430 battery |
| 005201 | 1 | No | No | 143*40*20mm | 1 3V CR2430 battery |
| 005204 | 1 | No | No | 90*80*11mm | 1 3V CR2430 battery |
| 005205 | 1 | No | No | 90*80*11mm | 1 3V CR2430 battery |
| TEL_AC170 | fifteen | Aha | Aha | 120*40*10mm | 1 3V CR2430 battery |
| 005017 | 1 | No | No | 130 x 44 x 10.5 mm | 1 3V CR2430 battery |
| 005018 | fifteen | No | No | 130 x 44 x 10.5 mm | 1 3V CR2450 battery |
| 005019 | 1 | Aha | Aha | 130 x 44 x 10.5 mm | 1 3V CR2450 battery |
| 005217 | 1 | No | No | 65*50*25 mm | 1 battery 12V 27A |
| 005051 | 1 | No | No | 86*86*15 mm | 1 3V CR2430 battery |
| 005054 | 1 | Aha | Aha | 86*86*15 mm | 1 3V CR2430 battery |
Compatible with remote control
These controls are exceptionally compatible with domis.pro radio-electric motors and domis.pro radios and are ideal for a unidirectional motor, that is, a classic motor. For a bidirectional motor, that is, with feedback, bidirectional remote controls are preferable in order to be able to take full advantage of their advantages. The bi-directional motor can be controlled using these unidirectional remote controls, however, the feedback function will not be available. Bidirectional models are mentioned on product listings, and can also be identified by the mention of "domis.pro CONNECT".
Our consultants are at your disposal to help you make the right decision if you need it.
Proudly show off your remote controls
Remote controls for blinds and awnings are an integral part of the decor, if you fix them on the wall (stand included, removable remote controls). We have collected a collection of stylish remotes for you, judge for yourself!
Discover our Connected Home Box for motorized blinds and blinds with AvosDim Radio tubular motors or compatible with all AvosDim radios. Regardless of whether the motor is unidirectional or bidirectional, with the 005313 box, you can control the blinds or blinds from your smartphone and using Alexa and Google Assistant voice commands. Whether you are in the office or abroad, your phone order will be instant. And script recording allows you to schedule opening and closing according to your own criteria for offline operation. After the mailbox is requested, the use of the mobile application becomes absolutely free. Access can be shared with other family members.
